You survey.
We draft.
We pick up your raw field data and hand back plot-ready sheets in your own CAD standards — without the cost or overhead of an in-house drafting team.
Built around the surveyor's day
From rough field data to plot-ready DWG — every part of the handoff is tuned for licensed survey crews.
Three disciplines.
One trusted partner.
Drafted like the field expected it.
A clear, audit-friendly handoff — from raw RW5/CSV to plot-ready PDFs and DWGs.
Send raw survey data (RW5, CSV, FBK, LandXML, DXF) and your CAD standards. We confirm scope same-day.
We model the surface, process traverse, plot linework on your layers, with title block & layouts.
Senior CAD lead reviews each sheet for layer/linetype/lineweight integrity and dimensional accuracy.
Plot-ready DWG + PDF + LandXML packaged with revision history. Revisions free for 7 days.
A drafting bench, on your terms.
- We adopt your CAD spec on day one — your layer table, plot styles, title block and ltscale stay yours.
- Coverage for every US state, every datum, every projection — including ALTA Table A items you select per job.
- Drafted natively in AutoCAD / Civil 3D / Carlson / MicroStation — never re-keyed from PDF screenshots.
- Mutual NDA signed before a single coordinate moves. Files purged on request after delivery.
Ready to draft
something real together?
From a single redline to a full outsourced drafting department — send your field data and we'll quote within 4 business hours.
